35mm Battery Cable – Precision Cut for Optimal Performance
- According to IEC and BS Standard
- Approved by ISO, CE, SGS
- Place of Origin: Henan, China
- Number of Cores:1
- HS Code: 8544492100
- Packing: 100 Meters
- MOQ: 500 Meters
5.8 $ / Meter
5
The 35mm battery cable is a battery connection cable designed for high current applications in electric vehicles (EV), solar energy storage systems, industrial battery packs and marine power systems. Its 35mm² cross-section ensures excellent conductivity and can carry up to 240A of continuous current for demanding power transmission needs. Each cable makes a secure and long-lasting connection by removing the pre-assembled sturdy 35mm cable lugs made of highly conductive copper with a corrosion-resistant coating. ZW Cable Manufacturer produces 35mm² battery cables with full durability and efficiency, and can be custom cut to length to meet your exact specifications.
Key Advantages
- Flexible stranded structure; easy to bend and install.
- Flame retardant PVC – UV and oil resistant.
- Lead-free, RoHS-compliant materials; 100% recyclable.
- It offers customization to meet the urgent needs of customers.
Cable Construction：
- Conductor: Plain annealed copper Class 5
- Insulation: PVC
- Sheath Color: Black, Red
35mm Battery Cable Specification:
| Parameter | Specification |
| 35mm Battery Cable Amp Rating | 240 Amps |
| 35mm Battery Cable Diameter | 14.5 mm |
| Voltage Rating | 600V DC / 1000V AC |
| Test Voltage | 2.5KV/5Min |
| Temperature Range | Max 90°C, Min -10 °C |
| Conductor Resistance | ≤ 0.536（Ω/KM) |
| Reference Weight | 430 kg/km |
| Bending Radius | 8x cable diameter |
